Video Showing How Energy Storage System Works

Solar Energy Storage Systems

This video explains how our small Residential Energy Storage Systems charge from solar panels during the day and then power the house at night, thus reducing electricity consumption and lowering your power bill. Another great feature of the Home Battery Storage System is the UPS function which ensures continuous electricity during a power outage.

The manufacturer warranties these Energy Systems for 5 years and the ones with 3000 Watts or 5000 Watts output come with a Solar Inverter and a Charge Controller. The Portable Storage Systems are designed for use in case of emergencies, in remote areas, health centers, disaster and rescue services, farms, electrical tools, and outdoor activities such as camping, hiking, or military use.

A storage system is different than a grid-tied solar system because rooftop solar panels won’t power your home during a power outage with the grid-tied system even if your panels are getting sunlight. A Battery Storage System allows you to pull power from your batteries instead of the grid even when the solar panels aren’t generating power.

Lithium Batteries are much preferred over Lead-Acid Batteries because of the longer lifespan and higher depth of discharge of the Lithium Batteries. Even though Lead-Acid Batteries cost a bit less, they have a shorter lifespan and require more maintenance which makes Lithium Batteries a much wiser choice for most applications.

Contact us for the perfect storage system for your needs at a great price!

Here are the specifications for the 4 models of 3000 Watts Battery Energy Storage Systems for Residential, Boat, and Light Commercial with a 5 Year Manufacturer’s Warranty:

Model – PS6530B - $4,090 for 1 each

Battery Power

·        Nominal Lithium Battery Pack Voltage: 48 Volts, 6,630Wh

Output

·        AC Output: 3000W (Voltage is adjustable); Pure Sine Wave, Power Frequency Inverter Output

·        Peak Output: 4000W

·        Output Voltage: 120V or 240V

·        Output Frequency: 50Hz/60Hz

·        Overload Ability: 120%<load<130% @10min; 130%<load<150% @10s

·        Equal to Off-line UPS Function

·        On/Off-grid Operation

·        Max Efficiency: 92% (>70% Load)

·        110VAC Output Power is 2000W

AC Charge

·        Input: Photo-Voltaic MPPT-2000W and AC 2400W Input

·        Input Voltage: 88-264VAC

·        Power Factor: >0.95 (full load)

·        Max Efficiency: 92%

PV Charge

·        Max Input Power: 2400W

·        Start-up Voltage: 75VDC

·        MPPT Amount: 2

·        MPPT Input Voltage: 75~140VDC

·        Max Input Voltage: 150VDC

·        MPPT Efficiency: 99.5%

·        Max Efficiency>96%

Additional Information

·        Relative Humidity: 5%~90%

·        Temperature: 32F~113F (0C~45C)

·        Dimensions: 30.6 * 13.7 * 35.9 in. (779 * 350 * 912 mm)

·        Weight: 297 Lbs. / 135 Kg

·        Shipping Weight: 363 Lbs. / 165 Kg

Model – PS7530B - $4,414 for 1 each

Battery Power

·        Nominal Lithium Battery Pack Voltage: 48 Volts, 7,500Wh

Output

·        AC Output: 3000W (Voltage is adjustable); Pure Sine Wave, Power Frequency Inverter Output

·        Equal to Off-line UPS Function

·        On/Off-grid Operation

AC Charge

·        Input: Photo-Voltaic MPPT-2000W and AC 2400W Input

Additional Information

·        LCD Display

Model – PS8030B - $4,538 for 1 each

Battery Power

·        Nominal Lithium Battery Pack Voltage: 48 Volts, 8,000Wh

Output

·        AC Output: 3000W (Voltage is adjustable): Pure Sine Wave, Power Frequency Inverter Output

·        Peak Output: 4000W

·        Output Voltage: 120V or 240V

·        Output Frequency: 50Hz/60Hz

·        Overload Ability: 120%<load<130% @ 10min; 130%<load<150% @ 10s

·        Equal to Off-line UPS Function

·        On/Off-grid Operation

·        Max Efficiency: 92% (>70% Load)

·        110VAC Output Power is 2000W

AC Charge

·        Input: Photo-Voltaic MPPT-2000W and AC 2400W Input

·        Input Voltage: 88~264VAC

·        Power Factor: >0.95 (full load)

·        Max Efficiency: >92%

PV Charge

·        Max Input Power: 2400W

·        Start-up Voltage: 75VDC

·        MPPT Amount: 2

·        MPPT Input Voltage: 75~140VDC

·        Max Input Voltage: 150VDC

·        MPPT Efficiency: 99.5%

·        Max Efficiency: >96%

Additional Information

·        Relative Humidity: 5%~90%

·        Temperature: 32F~113F (0C~45C)

·        Dimensions: 30.6 * 13.7 * 35.9 in. (779 * 350 * 912 mm)

·        Weight: 346 Lbs. / 157 Kg

·        Shipping Weight: 381 Lbs. / 173 Kg

Model – PS12030B - $7,070 for 1 each

Battery Power

·        Nominal Lithium Battery Pack Voltage: 48 Volts, 12,000Wh

Output

·        AC Output: 3000W (Voltage is adjustable); Pure Sine Wave, Power Frequency Inverter Output

·        Peak Output: 4000W

·        Output Voltage: 120V or 240V

·        Output Frequency: 50Hz/60Hz

·        Overload Ability: 120%<load<130% @ 10 min; 130%<load<150% @ 10s

·        Equal to Off-line UPS Function

·        On/Off-grid Operation

·        Max Efficiency: 92% (>70% Load)

·        110VAC Output Power is 2000W

AC Charge

·        Input: Photo-Voltaic MPPT-2000W and AC 2400W Input

·        Input Voltage: 88~264VAC

·        Power Factor: >0.95 (full load)

·        Max Efficiency: 92%

PV Charge

·        Max Input Power: 2400W

·        Start-up Voltage: 75VDC

·        MPPT Amount: 2

·        MPPT Input Voltage: 75~140VDC

·        Max Input Voltage: 150VDC

·        MPPT Efficiency: 99.5%

·        Max Efficiency: >96%

Additional Information

·        Relative Humidity: 5%~90%

·        Temperature: 32F~113F (0C~45C)

·        Shipping Weight: 527 Lbs. / 239 Kg

Order the 3000 Watts Energy Storage System Here

100Ah Lithium Battery With Over 3,000 Charge Cycles

100Ah LiFePO4 Lithium Batteries

The battery I often recommend for many applications is a 100Ah Lithium Battery which is encased in Aluminum to dissipate heat and increase the life of the battery. This cell has a charge cycle life of over 3,000 cycles which is well above many similar batteries which may have a cycle life of only about 2,000 cycles. As always, price breaks are available for this battery starting at 16 each. Complete pricing and specifications are available at the link above.

Here’s a quick rundown of why Aluminum Encased Lithium Batteries Perform Better:

A typical aluminum encased battery that has better heat dissipation will start out with a higher cycle life.  Dependent upon the size of the cell the expectant charger cycle life of a smaller LifePO4 cell can be as much as 4000 charge cycles and follow the same trajectory of the plastic prismatic cell shown below.  The simple fact is that if you have an application where you want a long life, like for solar storage, and you do not discharge the cells below their nominal 3.2 voltage you will have a cell that will probably outlive you.  Depth of discharge has a very profound effect on a lithium battery’s life.

What is the Life Expectancy of the Aluminum Batteries?

-      Factor 1: Depth of Discharge…Percentage of Capacity Used Per Cycle.

-      DOD, short for the Depth of Discharge, is used to describe how deeply the battery is discharged. If we say a battery is 100% fully charged, it means the DOD of this battery is 0%, If we say the battery have delivered 30% of its energy, here are 70% energy reserved, we say the DOD of this battery is 30%.

-      Factor 2: Discharge Rate, The AMPS Divided by the Capacity

-      To Read the Chart Above, Here are Some Examples

A.   All Numbers are at a 1C Discharge Rate, Which is Aggressive…

B.   At a 90% Depth of Discharge, Our Batteries Will Provide 2400 Cycle to 80% State-of-Original-Capacity (SOIC)

C.   At a 10% Depth of Discharge (Say, Engine Starting) Our Batteries Will Provide 35,000 Cycles Until 80% SOIC. Beyond 35,000 Cycles the Battery is Still Functioning But Gradually Losing Capacity, but not Performance

Conclusion: By recharging a lithium battery more frequently, thus reducing the DOD (depth of discharge), the battery cycle life is Increased. Solar is very often a beneficial method to reduce DOD and increase life!

View the 100Ah Lithium Battery Here

Specifications for 100Ah LiFePo4 Lithium Battery:

NOMINAL/MINIMUM CAPACITY	100Ah @ 1/3C Discharge
MAX DISCHARGE CURRENT (continuous)	200A (2C)
STANDARD CHARGE CURRENT	50A (0.5C)
MAX PULSE CHARGE CURRENT (<10 sec)	100A (2C)
MAX PULSE DISCHARGE CURRENT (<5 sec)	500A
NOMINAL VOLTAGE	3.2
SUGGESTED MAX CHARGE VOLTAGE	3.65
END OF DISCHARGE VOLTAGE	2.2
CYCLE LIFE AT STANDARD (80%)	>3000
INTERNAL RESISTANCE/IMPEDANCE (milliohms)	1
SUGGESTED CHARGING CURVE	Constant Amperage to 3.65V, Constant Voltage, Decrease Amperage, Stop at 1A Charge
CHARGE WORKING TEMP F (C)	32 to 122 (0 to 50)
DISCHARGE WORKING TEMP F (C)	-4 to 122 (-20 to 50)
STORAGE TEMP F (C)	14 to 113 (-10 to 45)
ENERGY TYPE	3V-3.2V-3.65V, 100Ah EV, Lithium, LiFePO4, LFP Aluminum Shell Battery

Connect your new 100Ah EV, Lithium, LiFePO4, LFP Aluminum Shell Battery pack together in parallel (neg to neg and pos to pos) for 24 hours before connecting in series and charging. This gives your new batteries time to balance their voltages to a degree.

It is also strongly suggested that you use a BMS or balancing system for your new 100Ah EV, Lithium, LiFePO4, LFP Aluminum Shell Battery pack.

Always use caution when working with high voltages.

Pricing Options

Quantity	Price From Factory in China*
98+	$115
48-97	$118
16-47	$123
4-15	$127

*Plus Air Freight Shipping (approx. $37 each for shipping in the Continental USA)

Delivery by Air is approximately 15 Days.

Delivery by Ocean Freight to Long Beach Seaport is 6 to 8 Weeks.

The buyer shall be responsible to arrange and pay for the overland shipping of these batteries from the Long Beach, California, seaport to their address.

Note: Ocean Shipping is only available on larger quantity orders (approximately 50 batteries). Smaller orders must be shipped by Air.
